7
All sizes mentioned on this page represent mm
1
Section
Select the installation part from the following two types.
Select the card holder from two types (L and S).
■
Installation parts
■
Card holder
LINE
Solor LINE
LED type
Flashing pattern
LED color
Dimensions Cord length Double-sided cushion tape
LINE
Lamp type, 3 mm
diameter, 3 LEDs
Flashes from left to
right one after another.
Blue, white, red
50×28mm
－ One for the top and one for the
bottom surface
Solor LINE Lamp type, 3 mm
diameter, 3 LEDs
Flashes from left to
right one after another.
White
Board：50×28mm 250mm
One for the top and one for the
bottom surface of the board
Panel：58×33mm
Only for the back of the panel
19424
19421
19422
19423
Mechanical Products - LED
HANABI
Solar HANABI
LINE
Solar LINE
Mini-Furimo
Kurumo
SUNTA
Column I
Column II
Column III
PAUSE
Messenger
Memory Talker
Aromachine
Mechanical
Products
FLASH
BATTERY
SOLAR
Click here for videos
(Same video as page 4)
■
LINE usage examples
The following kinds of visual effects can be produced by utilizing the flow of light!
The flow of fluid
Direction
Stage
Click here for videos
Differences in HANABI flashing patterns. LEDs flash from left to right as if the light is flowing.
Card holder（L）
●
Size:W114×H65mm
●
Material:PET
Card holder（S）
●
Size:W88×H38mm
●
Material:PET
●
Size:
W88×D55mm
●
Material:PET
Blue
White
White
Red
Gondola attachment
A two-way structure that
can be used as a price card
rail and as a mechanism that
prevents goods from falling off
Multi-adapter
A three-way structure that
does not restrict installation
locations
●
Material:POM
Used as a price
card rail
Used as a
mechanism that
prevents goods
from falling off
Used on
a glass shelf
