8
Mini-Furimo
18460
79
35
24
49
POP swings right and left like a pendulum.
Up to three POP items can be moved at the same time.
The top and middle items swing in the same direction, and
the bottom item swings in the reverse direction.
Be sure to use this option to maintain levelness.
There is a danger that magnetism will cause operational faults, so the
main unit should be kept at least 10 mm away from any steel parts.
Solar panel
W35×D13×H1mm
Cord length
180mm
Dimensions: Main unit
W35×D24×H49mm(With the arm:H79mm)
Material
Heat resistant ABS
Heat resistance
110ºC
Cold resistance
-10ºC
Can be installed on vending machines
Material: 12-gram steel
SOLAR
Pendulum movement is more attention-getting. Solar power means no power supply required!
Attach to the
base of the
pendulum inside
this product.
MOVING
Paper diameter
Paper thickness
Weight
Without the weight
φ100
Cardboard: Approx. 0.34 g
Approx. 2.6 g
With the weight
φ140
Cardboard: Approx. 0.34 g
Approx. 4.8g
Maximum load (as a guide) when installed directly on the main unit
●
Material: POM
1
Section
■
Optional weight
12236
This option is a useful way to adjust the balance and
change the speed of the movement.
■
Optional shelf ratchet
15577
This option can be easily installed on a shelf.
