Section
■
Optional parts
AC adapter
19657
●
I/P AC 100V 50/60Hz 3VA
●
O/P DC1.5V 30mA
●
Cord length: 1.5 m
●
Material: ABS
●
This option is based on
specifications applicable only in
Japan. Please consult with Wayo
if any accessories are required.
Optional parts ① to ⑨
are sold as a set with the
main unit.
11451
Click here for videos
HANABI
Solar HANABI
LINE
Solar LINE
Mini-Furimo
Kurumo
SUNTA
Column I
Column II
Column III
PAUSE
Messenger
Memory Talker
Aromachine
Mechanical
Products
Mechanical Products - Rotating Mechanisms
Vertical load
100g 200g 300g
Alkaline
battery
AAA
battery x
2
Parallel
connection
1.5V 200h 170h 100h
Manganese
dioxide
battery
1.5V 95h
80h
50h
Battery life
Turntable specifications
AAA alkaline battery
AC adapter（1.5V 30mA）
HI
Approx. 12 revolutions min Approx. 18 revolutions min
LO Approx. 6 revolutions min Approx. 9 revolutions min
① Base plate ② Rotary top ③ Sliding top ④ First arm ⑤ Second arm ⑥ Fulcrum
top
⑦ Adhesion
top
⑧ Connection
boss
⑨ Stand
■
Pendulum
■
Lateral movement
■
Vertical movement
Swing angle: The swing angle of the
pendulum can be selected from four
different settings (approx. 60º, 76º, 80º
and 99º).
Movement distance: The stroke length
can be selected from four different
settings (30 mm, 40 mm, 50 mm and
60 mm)
Movement distance: The stroke length
can be selected from four different
settings (30 mm, 40 mm, 50 mm and
60 mm)
Column III
11450
46 φ
40
62
48
HI
LO
Rotational direction
change switch
Power supply
Built-in batteries (two AAA batteries)
AC adapter (3V)
* No battery is included.
Column III provides the same turntable function as Column I and Column II,
and can also produce three more movements (vertical, lateral and pendulum) if
optional parts are used.
The rotary top can be used to adjust the movement distance. (Four settings for
each movement)
The direction of rotation can be changed with the switch. (Turntable
specifications)
Vertical withstand load during rotation (turntable specifications)
2.4 kg
Withstand load during vertical, lateral or pendulum movement
23 g
A multifunctional moving mechanism that can provide four roles: a turntable, vertical movement, lateral movement,
and pendulum movement.
