15
All sizes mentioned on this page represent mm
1
Section
Click here for videos
PAUSE
19321
・
19322
Item
Specifications
External dimensions of the
motor mechanism
Height: 50 mm (excluding the base mounting protrusions)
Width: 80 mm; Depth: 63 mm
Weight of the motor
mechanism
112 g (excluding external batteries)
Materials
ABS resin, POM resin
Operating temperature range
Between -10ºC and +40ºC
Operating humidity range
Between 30% and 90% (no condensation)
Power supply
AA battery x 2 or AC adapter (3 V)
Behavioral specification
Operating for approximately two seconds and stopping for
approximately five seconds
Battery life
Approximately 31 days, assuming that the motor operates
every five seconds, an optical sensor for detecting daytime
and nighttime is incorporated, two AA batteries are used,
and the product operates 12 hours a day
This product repetitively revolves, pauses and then revolves again.
Revolving increases the attention-getting effect, while pausing increases the
customer notification recognition effect.
Select either the
triangular prism
specification or the
quadrangular prism
specification.
* These specifications
cannot be
interchangeably used
because dedicated
attachments are used.
Stops for two seconds
Repeats stopping for two seconds
Makes a one-third revolution
Stops for two seconds
Stops for two seconds
Repetitively makes quarter revolutions
Makes quarter revolutions
HANABI
Solar HANABI
LINE
Solar LINE
Mini-Furimo
Kurumo
SUNTA
Column I
Column II
Column III
PAUSE
Messenger
Memory Talker
Aromachine
Mechanical
Products
Mechanical Products - Rotating Mechanisms
Rotating advertisement: Standard sizes
Triangular prism specification: 77 (W) mm x 160 (H) mm x 3 surfaces
Quadrangular prism specification: 60 (W) mm x 160 (H) mm x 4 surfaces
* The width is fixed.
* The height can be freely changed.
(The maximum height for horizontal rotation is 300 mm.)
The advertisement must be prepared by the customer.
Template data can be downloaded from the following link:
Click here for download
Triangular prism specification
19321
Quadrangular prism specification
19322
A rotating mechanism that does not only attract attention but also makes customers read the advertisement
BATTERY
MOVING
Horizontal rotation is
also possible.
(Maximum size of
printed matter: 300
mm wide)
This is an effective
notification method
that makes the best
of limited space.
50
80
63
