6
Section
85
TILT DISPLAY
STAND SERIES
MOTION
SERIES
STEEL STAND
SERIES
TILT DISPLAY STAND SERIES
DISPLAY SERIES
All sizes mentioned on this page represent mm
TS21-EF-SSL
11852
TSH10-CE-BSL
16904
TS11-BA-BSS
11814
TSH02-BB-BBL
16905
Table F 50x100mm
Arm SSL 7φx7φx100mm
Base E 70x70mm
PC Elastomer
Table E 70x70
Arm BSL 9φx7φx100mm
Base C 100x100mm
PC Elastomer
Table A 70φ
Arm BSS 9φx7φx50mm
Base B 100φ
PC Elastomer
Table B 100φ
Arm BBL 9φx9φx100mm
Base B 100φ
PC Elastomer
Merchandise appears to be flying in the air.
Flexible functions matched to the consumers' eye level.
Easily assembled.
Light weight/Compact/High quality
①Elastomer, slip resistant
material on the surface
maintains stability
③Can rotate
360°freely.
◆How to read
the chart
above
■
Original Order
②Can rotate
in any
direction.
◆Parts introduction
【Table and Base】
【Hold Parts】
【Arm】
■
Tilt variation
Example：
B
type
E
type
Ball diameter
Length
Selectable from A to H type
Selectable from A to H type
Length is either 50mm
or 100mm
Base and arm can be
connected by holding parts.
(Applicable to B and C types)
Table
Arm
Base
