4
Section
77
DISPLAY HOOK
(FIXED TYPE)
PACKAGE
HANGER
DISPLAY HOOK (FIXED TYPE)
HOOK & HANGER SERIES
As paper content is more than 51%, it is
treated as paper.
There is no harmful gas when burned
and the combustion calories also
decrease.
F Tatamic eco arm diameter/Tip horizontal load limit
Size (L)
Load limit
Diameter of arm
Code no. for
2mm thick board
Code no. for
3mm thick board
40mm
1000g
(Maximum)
7.6φ
12325
12326
60mm
500g
12143
12144
80mm
400g
12145
12146
100mm
350g
12147
12148
20
12
●
Material : ABS
●
Material : PP with used paper
Boards usable
in thickness are
2mm and 3mm
F Tatamic arm diameter/Tip horizontal load limit
Size (L)
Load limit
Diameter of arm
Code no. for
2mm thick board
Code no. for
3mm thick board
40mm
700g
6φ
19043
19205
60mm
420g
10986
19206
80mm
280g
10988
19207
100mm
210g
10991
12018
130mm
70g
10993
12020
20
12
F TATAMIC
F TATAMIC ECO
Size
Compact
for folding
Just lift up to
complete
Horizontal
Board through hole
Board through hole
Usage
example
(In-company investigation)
(In-company investigation)
Usage
example
Sectional drawings
maximum diameter
F Tatamic/
F Tatamic eco
Horizontal
Load
Load
All sizes mentioned on this page represent mm
Size
