KJ SERIES ASSEMBLING EXAMPLES
MJ SERIES
KJ-C5C6-KJ1
11382
KJ-C5BC-KJ1
16984
KJ-C5C6-2KJ1
(KJ ratchet type)
18930
CARD HOLDER WITH SLIGHTLY
BIGGER CLIP
Clip fits materials up to 30 mm thick.
●
Base : KJ-C5
10240
●
Top : KJ-C6
10238
●
Joint : KJ-1
10236
CARD HOLDER WITH SLIGHTLY
BIGGER CLIP
Clip fits materials up to 30 mm thick.
●
Base : KJ-C5
10240
●
Top : KJ-BC
11563
●
Joint : KJ-1
10236
CARD HOLDER WITH SLIGHTLY
BIGGER CLIP
●
Clip fits materials up to 30 mm thick.
●
Base : KJ-C5
10240
●
Top : KJ-C6
10238
●
Joint : KJ ratchet
18796
+ KJ-1
10236
x 2 pcs
Adjustable board angle
Rotation fixed at pitch of 45° horizontally
Stops at 45°
C5C6 fixed type 90°
Stops at 90°
■
Rotating direction (Usage example)
Rotates at 45° pitch
to the axial and arm
directions.
■
Installation example
